Toegangspoort draaihek op volle hoogte
IM.SD.02
IM.SD.02 Full Height Turnstile is based on a blend of physical security and smart access control features. It can support multiple types of verification, a pair of anti-tailgating and anti-reverse, and has a two-way flexibility to provide efficient and safe movement in the high-traffic conditions.
-
Arm Length：500Mm
-
Doorgangsbreedte:550-600Mm
-
Passing Speed:≤ 35 mensen/min
-
Materiaal：304 Stainless Steel Material
-
Dimensies：Length 2530* Width 1550* Height 2170mm
Gezichtsherkenning
LED-display
8 Paren infrarooddetectoren
QR
Access control turnstile full height systems are specifically controls and limit the movement of people in sensitive or high risk environments. These models will reach all the way up to the overhead as opposed to half-height barriers which will eliminate the possibility of climbing, tailgating or unauthorized intrusion. Bijgevolg, they offer unparalleled schemes to the control of places like industrial plants, ports, correctional facilities and closed corporate compounds.
Access control turnstile is a rotating machine with a three arm full height frame. The number of people going through it in one rotation is limited to one, which greatly increases the accuracy of control. Bovendien, it has SUS304 stainless steel in the structure the structure and this material has excellent durability, rust resistance, and weatherproof capabilities both on an indoor and an outdoor environment.
Functies
- Anti-climbing frame of full height to allow entry.
- Mechanical rotation accessing one-person-per-cycle.
- Stainless steel corrosion and impact resistance body.
- RFID, biometrisch, QR, and palm vein validation.
- Fire alarm integrated emergency unlock.
- Live tailgating and forced entry alarms.
- Voice and LED support to aid in user navigation.
- Adjustable to either a one-way flow or a bi-directional flow.
In order to facilitate more safety, it has a fire linkage feature that opens the gate automatically in cases of emergencies. Bovendien, the system will be able to produce real time audio and visual warnings. Maintenance is also efficient, the internal modular components enable the servicing to be done quickly with minimum downtime.
- Productdetails
- Specificaties
- Technical & Features
- Aanpassingsvermogen
- Toepassing
Productdetails
Industry-Grade Material & Structure
- Materiaal: 304 stainless steel material, top box and guardrail thickness 1.2mm, rotating arm thickness 2.0mm
- Corrosion Resistance: Passed ISO 9227 Salt Spray Test (2,000 hours rust-free)
- Temperature Range: -30C to +70C (Indoor/Outdoor Compatibility)
- Protection Rating: Water/Dust Resistance (Stable operation in heavy rain/dust)
Specificaties
Kerntechnische specificaties
| Dimensies | length 2530* width 1550* height 2170mm |
| Arm Length | 500Mm |
| Passing Direction | support one-way and two-way (facultatief) |
| Passing Speed | ≤ 35 mensen/min |
| Doorgangsbreedte | 550-600Mm |
| Power Supply Voltage | AC110-220±10%V 50HZ |
| Drive Current | > 200mA |
| Integratie | Supports ID card/IC card/QR code recognition/RS485/relay Interfaces |
Technical & Features
Technical and security features
Technological and Safety Attributes
- Two-way Traffic, Bidirectional Switching:
The turnstile is bidirectional and the direction of passage could be swapped back and forth depending on the real needs. Whether it is established to one-way entry, one-way exit or in two ways free passage, it can easily be obtained through simple operation which is very flexible to various usage scenarios. - Modes of Identification:
The turnstile has various identification methods to address the requirements of various users and application environments. It has the capacity to facilitate common ways of identification, like card swiping (IC-kaart, ID card), fingerprint recognition, Gezichtsherkenning, en wachtwoordinvoer. The user is able to select the right identification method based on his or her needs. - Anti-Reverse and Anti-Tailgating:
The turnstile will have anti-reverse and anti-tailgating functionality. The anti-reverse service will ensure that the staff members do not go through the turnstile in the reverse direction and cause confusion in managing entry and exit. The anti-tailgating feature can be useful in preventing several individuals after one authorized individual in order to pass through to make sure that no one is able to pass through the same time after the successful identification has been made, which would result in the strictness of the access control. - Direction Switching:
Use the control panel or the connected access control system to change the direction of passage of the turnstile. Operate the system according to the system instructions or the prompts on the control panel. - Identification and Passage:
To pass through, swipe the authorized card on to the card reading area, or even fingerprint/face scan or type in the right password, the user is required to do as listed. Once identified successfully, the turnstile will unlock and the user will be allowed to pass through in the given direction.
Aanpassingsvermogen
Wereldwijde marktaanpassing
- Spanning: 100-240V-breedbereik-ingang (Globale gridcompatibiliteit)
- Taalondersteuning: 24/7 Engelse dienst
- Certificering: DAT,FCC,ISO9001
Toepassing
Toepassingsscenario's
- Industrial Sites
- Transportation Hubs
- Stadiums and Arenas
- Prisons and Correctional Facilities
- Data Centers
